用处与详细资料/Brief Introduction：

该机组为10-20ml口服药方式药液溶液包装工作线中的主要的设施的设备。是由洗瓶、烤干移动教学整体机机和包装粘口移动教学整体机机所组合，能智能进行口服药方式药液瓶的洗瓶、烤干、包装和粘口等行动，是口服药方式药液工作的设备厂家更好的一起设施的设备，完完全全完全一致GMP需求。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

特别/Characteristic：

◆装量小于，避免出现渗漏。包装精密度较高。High filling accuracy.◆直流变频魔宗控速，生產的转速可以调整，能选择不一样的生產的转速。Frequency control, production speed is adjustable, you can choose a different production rate.◆其他小家电元器件封装均使用进囗的知名度企业品牌。All electrical components are imported famous brands.◆自动式表明运算功能表。Automatically countting function.◆把控好主要采用日本这个国家三菱数控系统PLC，抗抑制，岗位相对稳定。Controlled by Mitsubishi PLC◆性能方面可靠，服务器维护保養便利。Stable performance, easy maintenance.◆裸机样貌选用SUS304不锈304不绣钢钢板网作、与货品玩这部分选用316L304不绣钢。裸机非常按GMP的要求装修设计。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技能叁数/technical parameters：

适用性型号规格/Bottle size	10-20ml
生产方式作用/Capacity	60-90瓶/7分钟/60-90bottles/min
烤干溫度/Dryer tempreture	100-300°
使用流水量/Water wastage	0.5m3/h
洁净水耗量/Purifying water consumption	0.3m3/h
装量精确度/Filling precision	≤1%
电源开关/Voltage	380V/50Hz
最大功率/Power	33KW
工作线总长/Dimension	3500×1500×1600mm
