作用与百科/Brief Introduction：

机用户运用层次性三通管件分装阀，常用做水剂和膏霜类原辅料的分装，非常对高使用效果原辅料（如浓酱、辣子酱、番茄酱、种衣剂、微乳剂、透明桌面剂等）的使用效果相对比较严重，且精度等级高。机用户运用PLC可和程序编写设定，和6厘米手触屏组排用户界面系统的，进行 自主进瓶，自主分装，自主出瓶，电器开关，自动元机件均运用国际级国产品牌，抓实了经验丰富的产品和持续安全稳定的耐腐蚀性。本装置结构设计简单化，作业便宜，是中国梦想的针对性高使用效果原辅料的分装装置。机用户常备了避免 漏滴与不锈钢不锈钢拉丝的分装闷头，抓实分装之后后无漏滴，无不锈钢不锈钢拉丝。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

优势特点/Characteristic：

◆设定软件软件——用三菱PLCPLC设定软件软件，灌装生产线用量个数稍微调一下。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆运营软件工具栏——64英寸彩屏手触式运营软件工具栏，客观事物简单易行、安全保障可以信赖Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆技能模块键改进什么——开料有防渗漏系统，可选择原材料性质应有下潜分装技能模块键。（此技能模块键能能常用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电子电子器件电子器件——均应用国际联盟著名品店牌，切实保障机器的卫生可信、最准确高朝；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆设备器件——器机器件均主要包括更优质304不锈铝设计,知悉所需接触的面积材料可主要包括316L另缴费用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆记数测量——城市热力图记数，对的工作出现主观表示。Counting test, real-time, intuitive reflect the yield of work.◆罐装查测——无瓶不灌、瓶数不是不灌Bottle filling test - no bottle no filling, not enough◆维系的情况——远程服务器非常符合GMP规范，可容易取下、难以清理维系。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆掉换样式——修改包装样式时，只需要简洁修整，轻松自由搞好。Changing specifications - change the filling specifications, simply adjust, easy fix.◆干净搭配——搭配了干净构架，使机械的操作的氛围更好擦洗安全卫生。（此干净搭配还可以选择）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术水平产品参数/technical parameters：

装灌头数The number of filling head	8头（必选4、6、8、10、16个包装头）8 head (optional 4, 6, 8, 10, 12 filling he🍎ad)
适用于瓶径 Applicable bottles Drive	Ф33-Ф100 mm
测量的精密度measure precision	±1%
罐装储电量Canned capacity	150-1000ml
研发技能Production Capacity	2400-4000瓶/一小时2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
